JPL GRACE/GRACE-FO Gridded-AOD1B Water-Equivalent-Thickness Surface-Mass Anomaly RL06 dataset for Tellus Level-3 mascon 0.5-degree grid
This dataset will be available through Earthdata Cloud only, starting March 28th 2022. Learn More
AWS Calendar Icon
DOI10.5067/GGAOD-3MJ60
Short NameGRC-GFO_GRIDDED_AOD1B_JPL_MASCON_RL06
DescriptionGRACE non-tidal high-frequency atmospheric and oceanic mass variation models are routinely generated at GFZ as so-called Atmosphere and Ocean De-aliasing Level-1B (AOD1B) products (in terms of corresponding spherical harmonic geopotential coefficients) to be added to the background static gravity model during GRACE monthly gravity field determination. AOD1B products are 3-hourly series of spherical harmonic coefficients up to degree and order 180 which are routinely provided to the GRACE Science Data System and the user community with only a few days time delay. These products reflect spatio-temporal mass variations in the atmosphere and oceans deduced from an operational atmospheric model and corresponding ocean dynamics provided by an ocean model. The variability is derived by subtraction of a long-term mean of vertical integrated atmospheric mass distributions and a corresponding mean of ocean bottom pressure as simulated with the ocean model. For further details, please refer to https://www.gfz-potsdam.de/en/aod1b/. The Gridded AOD1B data sets provided here contain the monthly mean AOD1B data in geolocated gridded form, smoothed or spatially aggregated to be consistent with the GRACE and GRACE-FO Tellus Level-3 data products of land and/or ocean mass anomalies. With these gridded AOD1B Level-3 products, users can remove or add the effects of the modeled mean monthly atmospheric and ocean bottom pressure change (e.g., to compare different models).
VersionRL06
Dataset TypeACTIVE
MeasurementSOLID EARTH > GRAVITY/GRAVITATIONAL FIELD > GRAVITY ANOMALIES
Processing Level3
CoverageRegion: GLOBAL
North Bounding Coordinate: 89.5 degrees
South Bounding Coordinate: -89.5 degrees
West Bounding Coordinate: -180 degrees
East Bounding Coordinate: 180 degrees
Time Span: 2002-Apr-15 to Present
Granule Time Span: 2002-May-02 to 2021-Jun-01
ResolutionSpatial Resolution: 1 degrees (Latitude) x 1 degrees (Longitude)
Temporal Resolution: 1 Month
ProjectionProjection Type: Gridded
Ellipsoid: WGS 84
Platform/Sensor
GRACE-FO
Platform
Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO)
Orbit Period: -1.0 minutes
Inclination Angle: 89.0 degrees
/
GRACE-FO KBR
SENSOR
Name: GRACE-FO K-Band Ranging System (GRACE-FO KBR)
Swath Width: -1.0 kilometers
Description: Spacecraft angular distance from orbital plane relative to the Equator.

GRACE-FO
Platform
Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO)
Orbit Period: -1.0 minutes
Inclination Angle: 89.0 degrees
/
GRACE-FO SCA
SENSOR
Name: GRACE-FO Star Camera Assembly (GRACE-FO SCA)
Swath Width: -1.0 kilometers
Description: Spacecraft angular distance from orbital plane relative to the Equator.

GRACE-FO
Platform
Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO)
Orbit Period: -1.0 minutes
Inclination Angle: 89.0 degrees
/
GRACE-FO ACC
SENSOR
Name: GRACE-FO SuperSTAR Accelerometer (GRACE-FO ACC)
Swath Width: -1.0 kilometers
Description: Spacecraft angular distance from orbital plane relative to the Equator.

ProjectGRACE Follow-On (GRACE-FO)
Data ProviderPublisher: TELLUS
Creator: Felix Landerer
Release Place: JPL
Release Date: 2020-Mar-31
Resource: https://doi.org/10.1029/2011WR011453

Keyword(s)TELLUS, GRACE, GRACE-FO, LWET, Gravity, JPL, RL06, MASCON, AOD1B
Questions related to this dataset? Contact podaac@podaac.jpl.nasa.gov
Direct Access
PO.DAAC DRIVEhttps://podaac-tools.jpl.nasa.gov/drive/files/allData/tellus/L3/AOD1B/mascon_0.5-deg
PO.DAAC Drive
OPENDAP DATAhttps://podaac-opendap.jpl.nasa.gov/opendap/allData/tellus/L3/AOD1B/mascon_0.5-deg/
The OPeNDAP base directory location for the collection.
Web Servicehttps://podaac.jpl.nasa.gov/ws/search/granule/?datasetId=PODAAC-GGAOD-3MJ60
(Search Granule)
Format (Compression)NETCDF
Read Software
GENERAL DOCUMENTATION
USER'S GUIDE
DATA CITATION POLICY
Citation Felix Landerer. 2020. GRC-GFO_GRIDDED_AOD1B_JPL_MASCON_RL06. Ver. RL06. PO.DAAC, CA, USA. Dataset accessed [YYYY-MM-DD] at https://doi.org/10.5067/GGAOD-3MJ60

Download Citation
RIS XML JSON-LD

For more information see Data Citations and Acknowledgments.

Journal Reference Landerer F. W. and S. C. Swenson, Accuracy of scaled GRACE terrestrial water storage estimates. Water Resources Research, Vol 48, W04531, 11 PP, doi:10.1029/2011WR011453, 2012.

.
