CSR TELLUS GRACE-FO Level-3 Monthly Land Water-Equivalent-Thickness Surface Mass Anomaly Release 6.3 version 04
(TELLUS_GRFO_L3_CSR_RL06.3_LND_v04)Version | RL06.3v04 |
Processing Level | 3 |
Start/Stop Date | 2018-May-22 to Present |
Short Name | TELLUS_GRFO_L3_CSR_RL06.3_LND_v04 |
Description | This data set is produced by the Center for Space Research (CSR) GRACE-FO (Gravity Recovery and Climate Experiment Follow-On) program and derives the terrestrial water storage anomaly given as equivalent water thickness. These monthly grids are derived from GRACE-FO time-variable gravity observations during the specified timespan, and relative to the specified time-mean reference period. This quantity represents the total terrestrial water storage anomalies from soil moisture, snow, surface water (incl. rivers, lakes, reservoirs etc.), as well as groundwater and aquifers. A glacial isostatic adjustment (GIA) correction has been applied, and standard corrections for geocenter (degree-1), C20 (degree-20) and C30 (degree-30) are incorporated. Post-processing filters have been applied to reduce correlated errors. Data grids are provided in ASCII/netCDF/GeoTIFF formats. GRACE-FO was launched on 22 May 2018, and extends the original GRACE mission (2002 – 2017) and expands its legacy of scientific achievements in tracking earth surface mass changes. Version 04 (v04) of the terrestrial water storage data uses updated and consistent C20 and Geocenter corrections (i.e., Technical Notes TN-14 and TN-13), as well as an ellipsoidal correction to account for the non-spherical shape of the Earth when mapping gravity anomalies to surface mass change. Additionally, this release 06.3 is an updated version of the Level 3 products in coordination with the release of the analogous Level 2 products used to generate them. It differs from RL06.1 only in the Level-1B accelerometer transplant data that is used for the GF2 (GRACE-FO 2) satellite; see respective L-2 data descriptions. RL06.3 uses the ACX2-L1B data products. All GRACE-FO RL06.3 Level-3 fields are fully compatible with the GRACE RL06 data. |
DOI | 10.5067/GFLND-3C634 |
Measurement | TERRESTRIAL HYDROSPHERE > WATER BUDGET > TERRESTRIAL WATER STORAGE |
Platform/Sensor | GRACE-FO / Platform Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO) Orbit Period: 94.5 minutes Inclination Angle: 89 degrees GRACE-FO MWI SENSOR Name: GRACE-FO Microwave Instrument (GRACE-FO MWI) Swath Width: 24, 32 ghz Description: Microwave frequencies the instrument operates at. GRACE-FO / Platform Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO) Orbit Period: 94.5 minutes Inclination Angle: 89 degrees GRACE-FO LRI SENSOR Name: GRACE-FO Laser Ranging Interferometer (GRACE-FO LRI) GRACE-FO / Platform Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO) Orbit Period: 94.5 minutes Inclination Angle: 89 degrees GRACE ACC SENSOR Name: GRACE SuperSTAR Accelerometer (GRACE ACC) GRACE-FO / Platform Name: Gravity Recovery and Climate Experiment Follow-On (GRACE-FO) Orbit Period: 94.5 minutes Inclination Angle: 89 degrees GRACE-FO SCA SENSOR Name: GRACE-FO Star Camera Assembly (GRACE-FO SCA) |
Project | Gravity Recovery and Climate Experiment Follow-On (GRACE-FO) |
Data Provider | Publisher: PO.DAAC Creator: Felix Landerer Release Place: PO.DAAC Release Date: 2024-Oct-01 |
Format | netCDF-4 |
Keyword(s) | TELLUS, GRACE-FO, LWET, Gravity, CSR, RL06.3, Surface Mass, TERRESTRIAL WATER STORAGE, Ground Water |
Questions related to this dataset? Contact podaac@podaac.jpl.nasa.gov
Resolution Spatial Resolution: 1 Decimal Degrees x 1 Decimal Degrees Temporal Resolution: Monthly - < Annual Coverage Region: GLOBAL North Bounding Coordinate: 89.5 degrees South Bounding Coordinate: -89.5 degrees West Bounding Coordinate: -180 degrees East Bounding Coordinate: 180 degrees Time Span: 2018-May-22 to Present Granule Time Span: 2018-Jun-01 to 2024-Oct-01 Projection Projection Type: Gridded Ellipsoid: WGS 84 |
DIRECT ACCESS | |
Browse Granule Listing | |
Search Granules | |
DIRECT S3-ACCESS | |
Available for access in-region with AWS Cloud | |
Region | |
us-west-2 | |
podaac-ops-cumulus-protected/TELLUS_GRFO_L3_CSR_RL06.3_LND_v04/ | |
podaac-ops-cumulus-public/TELLUS_GRFO_L3_CSR_RL06.3_LND_v04/ | |
AWS S3 Credentials | |
Get AWS S3 Credentials | Documentation |
Name | Long Name | Unit |
---|---|---|
lat | latitude | degrees_north |
lat_bounds | latitude boundaries | degrees_north |
lon | longitude | degrees_east |
lon_bounds | longitude boundaries | degrees_east |
lwe_thickness | Liquid_Water_Equivalent_Thickness | m |
time | time | days since 2002-01-01T00:00:00 |
time_bounds | time bounds for each time value, i.e. the first day and last day included in the monthly solution | days since 2002-01-01T00:00:00 |
uncertainty | uncertainty | m |
GENERAL DOCUMENTATION | |
| |
| |
| |
USER'S GUIDE | |
| |
DATA CITATION POLICY | |
|
Citation is critically important for dataset documentation and discovery. Please cite the data as follows, and cite the reference papers when it is appropriate.
Citation | Felix Landerer. 2024. CSR TELLUS GRACE-FO Level-3 Monthly Land Water-Equivalent-Thickness Surface Mass Anomaly Release 6.3 version 04. Ver. RL06.3v04. PO.DAAC, CA, USA. Dataset accessed [YYYY-MM-DD] at https://doi.org/10.5067/GFLND-3C634
For more information see Data Citations and Acknowledgments.
|
||||||||
Journal Reference | Landerer F. W. and S. C. Swenson, Accuracy of scaled GRACE terrestrial water storage estimates. Water Resources Research, Vol 48, W04531, 11 PP, doi:10.1029/2011WR011453, 2012. . |
